Prerequisites for any charger on HARMON-E – FLEXECHARGE Help Desk

1. Charger is certified for compatibility by FLEXECHARGE

See list of certified chargers here: Charging Stations

Disable any other load or energy management, as to not interfere with the HARMON-E load manager

To operate perfectly, the load manager requires specific meter values in 15 second intervals from each charger.

Activate the following meter values through your CPMS:

AC Charging Stations	DC Charging Stations
Energy.Active.Import.Register Power.Active.Import Current.Import.L1 Current.Import.L2 Current.Import.L3	Energy.Active.Import.Register Power.Active.Import Current.Import.L1 Current.Import.L2 Current.Import.L3 SoC
Sampled Meter Data Interval
15 Seconds

Change the OCPP URL in the charger to point to HARMON-E. See here how it works: Add a charging station
